JB7590 waveform spring washer (waveform washer)

If you are looking for GB955 waveform elastic washer, please click http://www.bibnk.cn/products_view.asp?id=388 ）

Wave Spring Washers

(Wave washer)

65Mn、60Si2Mn、

Stainless steel, beryllium bronze, tin bronze

The following is a product introduction:

The full name of the product is Steel Waveform Spring Washers for Electric Motors (JB-T7590-2005), also known as Y-series Motor Waveform Washers_ Corrugated washer_ Wave spring_ Wave Huasi_ Corrugated gasket_ Wave pad.

Product specifications include Φ 8MM-240M, from 3 waves to 7 waves, common material is 65MN. The product is made of spring steel 65Mn (60Si2MnA/50CrVA/0Cr17Ni7Al/SUS304), which has undergone specific heat treatment and, depending on the specific situation, is generally controlled within the range of HRC44-55. The surface is blackened and has good elasticity. Waveform springs are widely used in industries such as motors, textile machinery, hydraulic equipment, and automobiles. They are mainly installed in bearing chambers or holes that are suitable for specifications (nominal sizes), with a small installation space and special functions of reducing noise and vibration.

The specifications and specific parameters are as follows:

Wave Spring Washers

(Wave washer)

65Mn、60Si2Mn、

Stainless steel, beryllium bronze, tin bronze
